Bluetooth 5.2/5.0 SIG Mesh self-organizing network, certified by the Bluetooth SIG, delivers fast and stable wireless smart control. Integrates four major wired dimming protocols—DMX512, 0-10V, triac, and DALI—with Bluetooth wireless smart control, delivering a hybrid wired+wireless lighting automation solution. Compatible with Chinese National Standard 86-type boxes, European-standard boxes, and US-standard boxes, it offers multiple product series for broader project applicability.
| Output Signal | DALI |
| Bus Power Current | 200mA@16V |
| Rated Parameters | 100-240V~，50/60Hz |
| Control Type | DIM, CT, RGB, RGBW, RGBCW |
| Wireless Type | Bluetooth 5.0 SIG Mesh |
| Compatible remote | B1、B2、B5、B8、RC4-BLE |
| Compatible APP | L-Home、 NFC Lighting |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x52mm(LxWxH) |
| Package Size | 102x102x73mm(LxWxH) |
| Weight | 130g |
| Output Signal | DMX512 |
| Rated Parameters | 100-240V~，50/60Hz |
| Control Type | DIM, CT, RGB, RGBW, RGBCW |
| Wireless Type | Bluetooth 5.0 SIG Mesh |
| Compatible remote | B1、B2、B5、B8、RC4-BLE |
| Compatible Driver | DMX driver, DMX decoder |
| Compatible APP | L-Home、 NFC Lighting |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x52mm(LxWxH) |
| Package Size | 102x102x73mm(LxWxH) |
| Weight | 130g |
| Output Signal | 0-10V |
| Rated Parameters | 100-240V~，50/60Hz |
| Control Type | DIM, CT |
| Wireless Type | Bluetooth 5.0 SIG Mesh |
| Compatible remote | B1、B2、B8、RC4-BLE |
| Compatible Driver | 0-10V dimming, color temperature drive |
| Compatible APP | L-Home、 NFC Lighting |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x52mm(LxWxH) |
| Package Size | 102x102x73mm(LxWxH) |
| Weight | 130g |
| Output Signal | Triac |
| Rated Parameters | 100-240V~，50/60Hz |
| Control Type | DIM |
| Wireless Type | Bluetooth 5.0 SIG Mesh |
| Compatible remote | B1、B2、B8、RC4-BLE |
| Compatible Driver | Triac driver |
| Compatible APP | L-Home、 NFC Lighting |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x52mm(LxWxH) |
| Package Size | 102x102x73mm(LxWxH) |
| Weight | 130g |
| Control Type | DIM |
| Wireless Type | 100-240V~ |
| Output Signal | DMX512 |
| Wireless Type | Bluetooth 5.2 SIG Mesh |
| Compatible Remote Control | B1 |
| Compatible Driver | B5-3A,DMX decoder |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x36mm(LxWxH) |
| Package Size | 113x112x50mm(LxWxH) |
| Weight | 155g |
| Control Type | CT |
| Wireless Type | 100-240V~ |
| Output Signal | DMX512 |
| Wireless Type | Bluetooth 5.2 SIG Mesh |
| Compatible Remote Control | B2 |
| Compatible Driver | B5-3A,DMX decoder |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x36mm(LxWxH) |
| Package Size | 113x112x50mm(LxWxH) |
| Weight | 155g |
| Control Type | RGB/RGBW/RGBCW |
| Wireless Type | 100-240V~ |
| Output Signal | DMX512 |
| Wireless Type | Bluetooth 5.2 SIG Mesh |
| Compatible Remote Control | B5 |
| Compatible Driver | B5-3A,DMX decoder |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x36mm(LxWxH) |
| Package Size | 113x112x50mm(LxWxH) |
| Weight | 155g |
| Output Voltage | 100-240V~ |
| Control Type | DIM,CT,RGB,RGBW,RGBCW |
| Output Signal | DMX512.DMX decoder |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x50mm(LxWxH) |
| Package Size | 105x105x63mm(LxWxH) |
| Weight | 225g |
| Output Voltage | 100-240V~ |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Compatible Driver | B5-3A, Bluetooth drivers and Bluetooth controllers |
| Number of Scenes | 8 scenes |
| Working Temperature | -25°C~50°C |
| Dimensions | 86x86x36mm(LxWxH) |
| Package Size | 113x112x50mm(LxWxH) |
| Weight | 225g |
| Control Type | DIM |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB1/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | CT |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB2/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | RGB/RGBW/RGBCW |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB5/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | Scene Control |
| Working Voltage | 3Vdc (1xCR2032 button battery) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Compatible Driver | B5-3A |
| Working Temperature | -15°C~50°C |
| Dimensions | 145x40x12mm(LxWxH) |
| Package Size | 148.5x46x19mm(LxWxH) |
| Weight | 50g±10g |
| Input signal | Bluetooth 5.2 SlG Mesh |
| Input voltage | 12-24V |
| Output voltage | 12-24V |
| Load current | 3Ax5CH Max.15A |
| Load power | 180W@12V 360W@24V |
| Protection | Short circuit, over-temperature, over-current protection, anti-reverse connection protection |
| Operating temperature | -25°C ~ 50°C |
| Dimensions | L91xW37xH21(mm) |
| Package Size | L94xW39xH22(mm) |
| Weight (G.W) | 46g |
| Wireless Protocol Type | Bluetooth 5.0 SIG Mesh,DMX/RDM |
| Output Voltage | 5-24Vdc |
| Input Voltage Range | 5-24Vdc |
| Load Current | 4A×5CH / 5A×4CH Max. 20A |
| Load Power | (0~20W...96W)×5CH Max. 480W |
| Protection | Short circuit, overcurrent, overheat, anti-reverse protection |
| Working Temperature | -20°C ~ 55°C |
| Dimensions | L175×W44×H30(mm) |
| Package Size | L178×W48×H33(mm) |
| Weight (G.W) | 130g |
| Input Voltage | 12-24VDC, Powered by Class 2 Power Supply |
| Wireless Type | Bluetooth 5.0 SlG Mesh |
| Compatible Devices | B5-3A, Bluetooth Driver, Bluetooth Controller |
| Number of Scene | 8 |
| Working Temperature | -25°C~50°C |
| Dimensions (L×W×H) | L120xW75xH30(mm) |
| Package size (L×W×H) | L158xW113xH62(mm) |
| Weight(G.W.) | 225g |
| Control mode | RGBWY |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | RGBW |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | CT |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | DIM |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Model: | GAM-BLE |
| Wireless Protocol Type: | Bluetooth 5.0 SIG Mesh |
| Output Signal: | 0-10Vx2CH / DMX |
| Working Voltage: | 12 ~ 24Vdc |
| Wireless Spectrum: | 2.4GHZ |
| Working Temperature: | -20°C ~ 55°C |
| Dimensions: | 125×33×20mm(L×W×H) |
| Package Size: | 127×35×22mm(L×W×H) |
| Weight(G. W.): | 60g |
